一，什么是ssl
SSL证书通过在客户端浏览器和Web服务器之间建立一条SSL安全通道（Secure socket layer(SSL)安全协议是由Netscape Communication公司设计开发。该安全协议主要用来提供对用户和服务器的认证；对传送的数据进行加密和隐藏；确保数据在传送中不被改变，即数据的完整性，现已成为该领域中全球化的标准。由于SSL技术已建立到所有主要的浏览器和WEB服务器程序中，因此，仅需安装服务器证书就可以激活该功能了）。即通过它可以激活SSL协议，实现数据信息在客户端和服务器之间的加密传输，可以防止数据信息的泄露。保证了双方传递信息的安全性，而且用户可以通过服务器证书验证他所访问的网站是否是真实可靠。
安全套接字层 (SSL) 技术通过加密信息和提供鉴权，保护您的网站安全。一份 SSL 证书包括一个公共密钥和一个私用密钥。公共密钥用于加密信息，私用密钥用于解译加密的信息。浏览器指向一个安全域时，SSL 同步确认服务器和客户端，并创建一种加密方式和一个唯一的会话密钥。它们可以启动一个保证消息的隐私性和完整性的安全会话。
首先要有一个主证书，然后用主证书来签发服务器证书和客户证书，服务器证书和客户证书是平级关系，SSL所使用的证书可以自己生成，也可以通过一个商业性CA（如Verisign 或 Thawte）签署证书。签发证书的问题：如果使用的是商业证书，具体的签署方法请查看相关销售商的说明；如果是知己签发的证书，可以使用openssl 自带的CA.sh脚本工具。如果不为单独的客户端签发证书，客户端证书可以不用生成，客户端与服务器端使用相同的证书。
二，安装所要的软件
openssl ：wget http://www.openssl.org/source/openssl-1.0.0a.tar.gz
apache： wget http://www.apache.org/dist/httpd/httpd-2.2.16.tar.gz
三，安装
在正式安装前，请不要直接看下面的安装，请看最后一部分，那是我安装时候所遇到的问题，这样可以使你少走不少弯路，我安装的时候，就走了不少弯路。
1，安装openssl
tar zxvf openssl-1.0.0a.tar.gz
cd openssl-1.0.0a
./config --prefix=/usr/local/openssl
make && make install
2,安装apache
如果你已经安装了apache，你又不想重新编译的话，请参考mod_ssl模块的安装，也就是添加ssl模块而已。
tar zxvf httpd-2.2.16.tar.gz
cd httpd-2.2.16
./configure --prefix=/usr/local/apache --enable-ssl --enable-rewrite --enable-so --with-ssl=/usr/local/openssl
make && make install
如果你是yum install ,apt-get,pacman这样的软件管理工具进行安装的话，上面的二步可以省掉。
3，创建主证书
在/usr/local/apache/conf/下面建个目录ssl
3.1，mkdir ssl
3.2，cp /openssl的安装目录/ssl/misc/CA.sh /usr/local/apache/conf/ssl/
3.3 用CA.sh来创建证书
[[email protected] ssl]# ./CA.sh -newca //建立主证书CA certificate filename (or enter to create)
Making CA certificate ...
Generating a 1024 bit RSA private key
............++++++
......++++++
writing new private key to './demoCA/private/./cakey.pem'
Enter PEM pass phrase:
Verifying - Enter PEM pass phrase:
Verify failure
Enter PEM pass phrase:
Verifying - Enter PEM pass phrase:
-----
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:cn
State or Province Name (full name) [Some-State]:cn
Locality Name (eg, city) []:cn
Organization Name (eg, company) [Internet Widgits Pty Ltd]:cn
Organizational Unit Name (eg, section) []:cn
Common Name (eg, YOUR name) []:localhost
Email Address []:[email protected]
Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:******************
An optional company name []:
Using configuration from /etc/ssl/openssl.cnf
Enter pass phrase for ./demoCA/private/./cakey.pem: //填的是上面的PEM密码
Check that the request matches the signature
Signature ok
Certificate Details:
Serial Number:
89:11:9f:a6:ca:03:63:ab
Validity
Not Before: Aug 7 12:35:28 2010 GMT
Not After : Aug 6 12:35:28 2013 GMT
Subject:
countryName = cn
stateOrProvinceName = cn
organizationName = cn
organizationalUnitName = cn
commonName = localhost
emailAddress = [email protected]
X509v3 extensions:
X509v3 Subject Key Identifier:
26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
X509v3 Authority Key Identifier:
keyid:26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
DirName:[email protected]m
serial:89:11:9F:A6:CA:03:63:AB
X509v3 Basic Constraints:
CA:TRUE
Certificate is to be certified until Aug 6 12:35:28 2013 GMT (1095 days)
Write out database with 1 new entries
Data Base Updated
安装成功的话，会在ssl目录下面产生一个文件夹demoCA
4 生成服务器私钥和服务器证书
[[email protected] ssl]# openssl genrsa -des3 -out server.key 1024 //产生服务器私钥Generating RSA private key, 1024 bit long modulus
.....................++++++
.........++++++
e is 65537 (0x10001)
Enter pass phrase for server.key:
Verifying - Enter pass phrase for server.key:
[[email protected] ssl]# openssl req -new -key server.key -out server.csr //生成服务器证书
Enter pass phrase for server.key:
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [AU]:cn
State or Province Name (full name) [Some-State]:cn
Locality Name (eg, city) []:cn
Organization Name (eg, company) [Internet Widgits Pty Ltd]:cn
Organizational Unit Name (eg, section) []:cn
Common Name (eg, YOUR name) []:localhost //要填全域名
Email Address []:[email protected]
Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:*****************
An optional company name []:
4.1 对产生的服务器证书进行签证
cp server.csr newseq.pem
[[email protected] ssl]# ./CA.sh -sign //为服务器证书签名Using configuration from /etc/ssl/openssl.cnf
Enter pass phrase for ./demoCA/private/cakey.pem:
Check that the request matches the signature
Signature ok
Certificate Details:
Serial Number:
89:11:9f:a6:ca:03:63:ac
Validity
Not Before: Aug 7 12:39:41 2010 GMT
Not After : Aug 7 12:39:41 2011 GMT
Subject:
countryName = cn
stateOrProvinceName = cn
localityName = cn
organizationName = cn
organizationalUnitName = cn
commonName = localhost
emailAddress = [email protected]
X509v3 extensions:
X509v3 Basic Constraints:
CA:FALSE
Netscape Comment:
OpenSSL Generated Certificate
X509v3 Subject Key Identifier:
FE:20:56:04:8E:B6:BE:3E:3A:E1:DA:A6:4A:3A:E1:16:93:1D:3F:81
X509v3 Authority Key Identifier:
keyid:26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
Certificate is to be certified until Aug 7 12:39:41 2011 GMT (365 days)
Sign the certificate? [y/n]:y
1 out of 1 certificate requests certified, commit? [y/n]y
Write out database with 1 new entries
Data Base Updated
Certificate:
Data:
Version: 3 (0x2)
Serial Number:
89:11:9f:a6:ca:03:63:ac
Signature Algorithm: sha1WithRSAEncryption
Issuer: C=cn, ST=cn, O=cn, OU=cn, [email protected]
Validity
Not Before: Aug 7 12:39:41 2010 GMT
Not After : Aug 7 12:39:41 2011 GMT
Subject: C=cn, ST=cn, L=cn, O=cn, OU=cn, [email protected]
Subject Public Key Info:
Public Key Algorithm: rsaEncryption
Public-Key: (1024 bit)
Modulus:
00:ce:d5:a8:df:d1:e7:ee:92:d1:d1:78:20:a9:6d:
0a:1b:f6:09:dd:13:29:ef:72:1d:17:54:dd:1c:8d:
28:27:69:fe:70:3b:fa:2b:a3:45:40:80:ea:0e:5b:
a7:bd:40:d0:cd:bc:2c:74:03:8b:f7:6c:5e:1f:09:
5d:c6:8a:05:ea:b8:72:fc:79:8b:62:62:38:0b:42:
28:7e:0d:fc:e7:bb:b0:87:66:6a:b2:35:92:91:b9:
78:9c:b6:76:01:0b:2a:74:df:5f:a1:8b:31:61:90:
93:f9:20:db:46:59:12:2e:9b:59:c0:32:4e:92:14:
a1:7e:52:7b:cc:02:5e:e2:45
Exponent: 65537 (0x10001)
X509v3 extensions:
X509v3 Basic Constraints:
CA:FALSE
Netscape Comment:
OpenSSL Generated Certificate
X509v3 Subject Key Identifier:
FE:20:56:04:8E:B6:BE:3E:3A:E1:DA:A6:4A:3A:E1:16:93:1D:3F:81
X509v3 Authority Key Identifier:
keyid:26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
Signature Algorithm: sha1WithRSAEncryption
09:a0:16:43:a2:93:11:a7:ab:f5:17:b7:36:35:84:9f:3b:37:
32:33:3f:93:63:b0:4c:bb:d1:b4:9b:4f:37:78:62:f4:ac:ff:
28:b0:63:71:2e:9a:7c:f4:40:2e:b1:5f:ae:49:e7:e2:6f:de:
cf:30:cc:9a:08:26:26:24:c5:00:03:32:20:48:41:b1:29:8f:
5d:3d:2a:78:54:0e:a8:76:07:6c:7f:23:42:75:c2:fb:83:1d:
70:44:5e:8c:90:cf:b4:23:b7:23:5b:06:05:32:58:e3:af:1c:
be:1d:50:7b:fd:37:66:ba:9c:ec:bb:af:ee:b6:04:f7:c5:2e:
59:22
-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----
Signed certificate is in newcert.pem
cp newcert.pem server.crt
5,产生客户端证书
生成客户私钥：
openssl genrsa -des3 -out client.key 1024
生成客户证书
openssl req -new -key client.key -out client.csr
签证：
openssl ca -in client.csr -out client.crt
转换成pkcs12格式，为客户端安装所用
openssl pkcs12 -export -clcerts -in client.crt -inkey client.key -out client.pfx
这一步根安装服务器的证书差不多，不同的是签证，最后安装的时候，client.pfx的密码要记住，在客户端安装的时候要用到的。
[[email protected] ssl]# openssl pkcs12 -export -clcerts -in client.crt -inkey client.key -out client.pfx
Enter pass phrase for client.key:
Enter Export Password:
Verifying - Enter Export Password:
客户端和服务器端都可以使用服务器端证书，所以这一步不做也行。
6，集中所以证书和私私钥到一起
#cp demoCA/cacert.pem cacert.pem
同时复制一份证书，更名为ca.crt
#cp cacert.pem ca.crt
7，apache配置
vi /usr/local/apache/conf/extra/ssl.conf
ssl开启SSLEngine on
指定服务器证书位置
SSLCertificateFile /usr/local/apache/conf/ssl/server.crt
指定服务器证书key位置
SSLCertificateKeyFile /usr/local/apache/conf/ssl/server.key
证书目录
SSLCACertificatePath /usr/local/apache/conf/ssl
根证书位置
SSLCACertificateFile /usr/local/apache/conf/ssl/cacert.pem
要求客户拥有证书
SSLVerifyClient require
SSLVerifyDepth 1
SSLOptions +StdEnvVars
记录log
CustomLog "/usr/local/apache/logs/ssl_request_log"
"%t %h %{SSL_PROTOCOL}x %{SSL_CIPHER}x "%r" %b"
vi /usr/local/apache/conf/extra/httpd_vhosts.conf
listen 443 httpsNameVirtualHost *:443
<VirtualHost _default_:443>
DocumentRoot "/home/zhangy/www/metbee/trunk/src/web"
ServerName *:443
ErrorLog "/home/zhangy/apache/www.metbee.com-error.log"
CustomLog "/home/zhangy/apache/www.metbee.com-access.log" common
Include conf/extra/ssl.conf
</VirtualHost>
vi /usr/local/apache/conf/httpd.conf把Include conf/extra/httpd-vhosts.conf前面的注释去掉
启动 /usr/local/apache/bin/apachectl -D SSL -k start
Server *:10000 (RSA)
Enter pass phrase:输入的是server的密钥
OK: Pass Phrase Dialog successful.
8,安装客户端证书
把ca.crt和client.pfx copy到客户端，双击client.pfx就会进入证书的安装向导，下一步就行了，中间会让你输入密码
四，安装所遇到的问题
1，生成的密码很多，一会让输入密码，会忘得，并且主证书的密码和下面的证书的密码不能重得，会报错的，所以要搞个文本记下来。
2，升级openssl引发的问题
httpd: Syntax error on line 56 of /usr/local/apache/conf/httpd.conf: Cannot load /usr/local/apache/modules/libphp5.so into server: libssl.so.0.9.8: cannot open shared object file: No such file or directory
httpd: Syntax error on line 56 of /usr/local/apache/conf/httpd.conf: Cannot load /usr/local/apache/modules/libphp5.so into server: libcrypto.so.0.9.8: cannot open shared object file: No such file or directory
用ln -s来建立软链接，就可以了。不过这种方法不是万能的，比如我把libpng从1.2升到1.4，libjpeg从7.0升到8.0结果是系统差点崩掉，用软链接不管用，我把他们弄掉，从网上下的低版本重装。
3，证书的国家名称，省名要相同不然生成空证书，
The countryName field needed to be the same in the
CA certificate (cn) and the request (sh)
4，提示CommonName时，要添写全域名，会提示警告
RSA server certificate CommonName (CN) `cn' does NOT match server name!?
5，相同的证书不能生成二次，名字不一样也不行，也就是说server.cst和client.csr信息不能完相同，不然会报
failed to update database
TXT_DB error number 2
6，页面浏览时，会看到提示，你的证书是不可信的，是因为我配置的不对，还是自己建的证书就是不要信的呢？
7，当我加了SSLVerifyClient require SSLVerifyDepth 1 这二个配置时，在windows下面，要你输入证书后，就可以看到页面了，但在用firefox就是不行呢？看下面的ssl_request_log日志，192.168.18.3是用windows的IE浏览器
[09/Aug/2010:22:02:21 +0800] 127.0.0.1 TLSv1 DHE-RSA-CAMELLIA256-SHA "GET /robots.txt HTTP/1.1" 208
[09/Aug/2010:22:02:21 +0800] 127.0.0.1 TLSv1 DHE-RSA-CAMELLIA256-SHA "GET /robots.txt HTTP/1.1" 208
[09/Aug/2010:22:02:21 +0800] 127.0.0.1 TLSv1 DHE-RSA-CAMELLIA256-SHA "GET /robots.txt HTTP/1.1" 208
[09/Aug/2010:22:02:55 +0800] 192.168.18.3 TLSv1 RC4-MD5 "GET / HTTP/1.1" 1505
[09/Aug/2010:22:02:55 +0800] 192.168.18.3 TLSv1 RC4-MD5 "GET / HTTP/1.1" 1505
[09/Aug/2010:22:02:55 +0800] 192.168.18.3 TLSv1 RC4-MD5 "GET / HTTP/1.1" 1505
遇到肯定不止这几个，有的想不起来了。关于6，7，还请高手指教。谢谢
